  1. 4 measurement modes (real-time measurement / maximum value / average measurement / automatic memory measurement)
  2. Internal memory for up to 100 measured values
  3. Statistics evaluation (MIN / MAX / average)
  4. Rotatable display
  5. Alarm function with multi-colored LED (yellow / green / red) and switching contact output 2.85 V.
  6. USB B interface
  7. Battery life up to 36 hours


The force gauge is a handy, digital measuring device for measuring tensile and compressive forces. The force measuring device offers a sampling rate of 500 Hz and various measurement options such as real-time measurement (RT), maximum value measurement (PEAK), configurable average value acquisition (Average) and automatic measurement storage of up to 100 measurements.

The measurement data and a statistical evaluation of the data stored in the force gauge (MIN / MAX / average) are shown on the graphic display and can be transferred to a PC via the USB interface. In addition, the force measuring device offers a limit value function MIN / MAX, which can switch a multi-colored LED (yellow / green / red) and switching contacts.

The graphic display can be rotated and the force gauge can be securely attached to a test stand using the M4 threaded holes on the back. The force is introduced into the internally installed load cell via an M6 threaded rod. Various mounting pieces are included in the scope of delivery of the force measuring device. The force measuring device can be operated continuously for up to 36 hours on a single charge (without background lighting) and is a reliable partner as a mobile force measuring device.

Force Gauge PFG 20

  • Measuring range 0 ... 20 N
    Resolution 0.005 N
    Accuracy ±0.3 % of the measuring range
    Measurement units N, kgF, lbF
    Display 1.8" graphic display
    Alarm modes Below, Inside, Outside
    Sampling rate 500 Hz
    Memory 100 measurements
    Power supply lithium battery 3.7 V / 1500 mAh
    Battery life up to 36 hours
    Power supply / USB charging adapter 5 V / 1 A
    Outputs interface: USB B
    Switching output / alarm modes: MD6 with 2.85 V if active
    Protection class IP 54
    Operating and storage conditions   5 ... 45 °C
    35 ... 65 % r.H. not condensing
    Force application M6 x 10 mm thread
    Dimensions 189 x 707 x 34 mm
    Weight 450 g
