GM 60 Plus Product VIdeo



Gloss Meter GM 60Plus-ICA for non-stationary use. Measurement up to 200 gloss points / 60 ° Measurement geometry / 3.5" TFT display / short measuring time of 0.5 seconds



The gloss tester GM 60Plus is a measuring device for the determination of gloss on different materials. During the measurement, the gloss tester picks up the reflection of emitted light. The light is emitted directly by the gloss tester. Part of the light is then reflected off the surface to be measured and part of the light is absorbed by the surface. Thanks to the reflected light, the gloss tester then calculates the degree of gloss and displays it clearly on the TFT display.



The gloss tester is used in areas where it is essential that individual products always have the same appearance and texture and properties. In this way, complaints and associated costs are avoided. In addition, the external reputation of companies with consistent quality and consistent products is respected or improved. Thus, the gloss tester GM 60Plus can assist you.

Gloss Meter GM 60Plus-ICA

  •
    Measuring geometry 60°
    Display 3.5" TFT touchscreen display
    Standards ISO 2813
    GB/T 9754
    ASTM D523
    ASTM D2457
    Measuring surface 9 x 15 mm / 0.36 x 0.60 in
    Measuring range 0 ... 200 GU
    Readability 1 GU
    Repeatability ±1 GU
    Reproducibility ±1 GU
    Chromaticity Fulfills CIE 1931 2° under a CIE illuminant C
    Measuring accuracy ±1.5 / ±1.5%
    Measuring time 0.5 second
    Dimensions 160 x 75 x 90 mm / 6.3 x 3 x 3.5 in
    Weight 350 g / 0.78 lb
    Menu languages English, Chinese
    Power supply 3200-mAh Li-ion rechargeable battery
    Data interface USB / RS-232
    Operating temperature  0 ... 40°C / 32 ... 104°F
    Storage temperature -20 ... 50°C / -4 ... 122°F
    Relative humidity < 85% RH (non-condensing)
