The material testing device sets a new standard for the quality control of concrete structures. With a wide range of measurement parameters and state-of-the-art technology, this material testing device enables accurate assessment of concrete piles, concrete beams, and other building components. This innovative material testing device provides not only reliable concrete strength measurements but also detailed error detection, including the size and depth of voids and cracks. The included camera even allows for precise measurement of crack widths.
Feature:
- - Measurement on concrete piles, concrete beams
- - Measurement parameters: Concrete strength, error detection, size and depth of voids, cracks
- - Includes a camera for measuring crack width
- - Bandwidth 1 to 500 kHz
- - Display: 10.1" TFT touchscreen display
- - Sturdy carrying case
- - Internal storage: 8 GB
Material Tester UCD 100
Measurement Range -1677700 µs ... +1677700 µs Resolution 0.05 µs Measurement Functions Detection of concrete piles, concrete strength, depth and width of voids, cracks Measurement Interval 0.05 ... 409.6 µs Display Type TFT color display Display Size 10.1 inches Data Interface USB Battery Capacity 8100 mAh Battery Voltage 11.1 V Battery Type Lithium-ion battery Bandwidth 1 ... 500 kHz Test Voltage 125 V, 250 V, 500 V, 1000 V Gain Range 146 dB Menu Language English, Chinese Protection Class IP20 Power Supply Mains, Battery Weight 2160 g Device Weight with Accessories 8152 g Device Weight with Accessories and Packaging 8700 g Dimensions (L x W x H) 300 x 200 x 58 mm Additional Dimensions Sensor Cable Length: approximately 10 m Operating Conditions 0 ... 50 °C, 10 ... 85 % r.F. Storage Conditions 0 ... 50 °C, 10 ... 85 % r.F.
